GFCI is a high-sensitivity, fast-response leakage protection device, which can quickly cut off the circuit and isolate the fault point when a dangerous ground fault leakage occurs, so as to avoid the occurrence of electrical accidents and ensure personal safety. The working principle of GFCI is that when there is equipment leakage or human body gets an electric shock, part of the current flows into the ground, and when the current flowing through the live wire and the neutral wire is not equal (the normal situation is equal), the GFCI monitors the current difference between the live wire and the neutral wire. Once the difference is greater than 6mA, the power supply can be cut off at the moment of 0.025 seconds, so as to ensure the safety of people and property. Widely used in homes, offices, hospitals, schools, hotels, factories and other outdoor venues.
1. This GFCI receptacle is made of nylon material resistant to oil pollution, suitable for industrial-grade machinery or equipment, designed without output terminals, in line with industrial-grade high-quality standards and safe operation
2. This GFCI outlet automatically conducts a self-test every 15 minutes to provide reliable protection and prevent the occurrence of ground faults. It meets the requirements of the National Electrical Code for ground fault protection
3. If the voltage is unstable (the voltage is lower than 90V or more than 180V), this GFCI socket will warn the user through the yellow LED light, and if no one handles it, it will automatically cut off the power after 5 minutes to protect your household appliances and equipment from damage damage.
4. This GFCI receptacle is suitable for 12 or 14AWG wires of side wire and back wire, meeting wide compatibility and diverse wiring needs, and can be easily installed in any electrical box.
5. This GFCI receptacle complies with the high quality standard and safe operation of home, office, bedroom and bathroom, which can continuously protect against ground faults and prevent personal injury and electrical fire risks caused by ground faults.
6. This GFCI outlet has a tamper-resistant outlet function, which protects children from electric shock by preventing objects from being inserted into the outlet slot, providing a safe choice for you and your family
7. This GFCI socket provides excellent corrosion resistance, temperature resistance and UV resistance, prevents discoloration and aging, is very suitable for outdoor and indoor use, and can prevent electric shocks that may occur due to electrical failures in humid environments.
Specification:
- Grounding: Standard Grounding
- Rated Voltage: 125V
- Rated Current: 20A
- Application: Residential/General-Purpose
- Electrical Characteristics: AC125V/20A
- Color:White
- Unloaded plug≥5000Sec Loop detection with automatic monitoring function
- Meet the standard:UL,CUL
- Housing material flame retardant grades
- Tripping threshold:5mA Tripping time<25ms
- Surge current:6000V/3000A 6000V/10KA
- Electric strength:Pressure resistance1500V 50Hz Duration 1Min
- Insulation resistance:>50MΩ(DC500V)
- Short-circuit current:10KA
- Insert and Draw Frequency>10000 times
- Temperature,humidity:-35℃ ~ +66℃; 20% ~ 90%
- Storage Temperature,Humidity: -20℃ ~ +85℃; 10% ~ 95%RH
